22 309941
Technical Data
Model 100–120V,
A, Hz
220–240V,
∅, A, Hz
Generator
Minimum
W
Motor HP (W) Cycles per
gallon (liter)
Maximum
Delivery gpm
(lpm)
Maximum
Tip size
Fluid Outlet
npsm
1 Gun 2 Guns
695 14, 50/60 9, 50/60 5000 1.75 (1300) 243 (64) 0.75 (2.8) 0.027 N/A 1/4 in.
795 15, 50/60 10, 50/60 5000 2.00 (1490) 195 (52) 0.95 (3.6) 0.031 0.021 1/4 in
1095 15, 50/60 10, 50/60 5000 2.20 (1640) 123 (33) 1.1 (4.1) 0.033 0.023 1/4 in
1595 20/15,
50/60
N/A 5000 2.5 (1860) 110 (29) 1.25 (4.7) 0.037 0.025 1/4 in
Basic Sprayer Wetted Parts: . . . . . . . . . . . . . . . . . . . . . . . . . . . .
zinc- and nickel-plated carbon steel, nylon, stainless
steel, PTFE, Acetel, leather, UHMWPE, aluminum,
tungsten carbide, PEEK, brass
Noise Level
Sound power 91 dBa*. . . . . . . . . . . . . . . . . . . . . . . . .
Sound pressure 82 dBa*. . . . . . . . . . . . . . . . . . . . . . .
* per ISO 3744; measured at 3.1 feet (1 m)
Dimensions
Model Weight lb (kg) Height in. (cm) Length
Width
Lo-Boy Hi-boy Lo-Boy Hi-Boy
in. (cm) in. (cm)
695 94 (43) 94 (43) 26.5 (67.3) Handle down,
38.8 (98.6) Handle up
28.5 (72.4) Handle down,
38.75 (98.4) Handle up
25.75
(65.4)
20.5
(52.1)
795 98 (45) 98 (45) 26.5 (67.3) Handle down,
38.8 (98.6) Handle up
28.5 (72.4) Handle down,
38.75 (98.4) Handle up
25
(63.5)
20.5
(52.1)
1095 N/A 120 (55) N/A 29.5 (74.9) Handle down,
38.5 (97.8) Handle up
26 (66) 22.5
(57.2)
1595 N/A 125 (57) N/A 29.5 (74.9) Handle down,
38.5 (97.8) Handle up
26 (66) 22.5
(57.2)
Graco Phone Number
TO PLACE AN ORDER OR FOR SERVICE, contact your Graco distributor, or call 1–800–690–2894 to identify the
nearest distributor.
All written and visual data contained in this document reflects the latest product information available at the time of publication.
Graco reserves the right to make changes at any time without notice.
Sales Office: Minneapolis
International Offices: Belgium, Korea, Hong Kong, Japan
www.graco.com
PRINTED IN USA 309941 12/2003, Revised 5/2004
