Graco X5 User Manual

Technical Specifications
52 3A3208B
Width
X5
12.4 in. 31.5 cm
X7
15.3 in. 38.9 cm
ProX17, ProX19 Stand
13.2 in. 33.5 cm
ProX21 Stand
13.5 in. 34.3 cm
ProX17, ProX19 Cart
17.2 in. 43.7 cm
ProX21 Cart
20.6 in. 52.3 cm
Weight
X5
16.5 lb. 7.5 kg
X7
26.5 lb. 12.0 kg
ProX17, ProX19 Stand
27.3 lb. 12.4 kg
ProX21 Stand
25.0 lb. 11.3 kg
ProX17, ProX19 Cart
37.5 lb. 17.0 kg
ProX21 Cart
49.5 lb. 22.5 kg
Storage temperature range XY
–30° to 160°F
–35° to 71°C
Operating temperature range 
40° to 115°F
4° to 46°C
Materials of Construction
Wetted materials on all models stainless steel, brass, leather, ultra-high molecular weight
polyethylene (UHMWPE), carbide, nylon, aluminum, PVC,
polypropylene, fluoroelastomer, plated steel
Notes
* Startup pressures and displacement per cycle may vary based on suction condition,
discharge head, air pressure, and fluid type.
X
When pump is stored with non-freezing fluid. Pump damage will occur if water or
latex paint freezes in pump.
Y
Damage to plastic parts may result if impact occurs in low temperature conditions.

Changes in paint viscosity at very low or very high temperatures can affect sprayer
performance.
US Metric

Graco X5 Specifications

General

Type	Airless Paint Sprayer
Maximum Hose Length	75 ft
Maximum Pressure	3000 PSI
Weight	15 lbs
Flow Rate	0.27 GPM
Recommended Annual Use	125 gallons per year
Hose Length	25 ft
Power Source	Electric
Voltage	120 V
Tip Size	0.015 in
Maximum Tip Size	0.015 inch
