Parts
3A7469D 15
XTR5+ Parts List
Ref. Part Description
Quantity
XTR520 XTR521 XTR522 XTR523 XTR524 XTR525 XTR530
1
19B236 BODY, gun 1 1 1 1 1 1 1
2*
245881 SEAL, retainer assembly 1 1 1 1 1 1 1
3*
--- GASKET 1 1 1 1 1 1 1
4
19B237 CAP, end 1 1 1 1 1 1 1
5
117350 SPRING 1 1 1 1 1 1 1
6
15E088 RETAINER, needle 1 1 1 1 1 1 1
7
15E085 PIN, actuator 2 2 2 2 2 2 2
8*
18C010 NEEDLE 1 1 1 1 1 1 1
9*
156766 GASKET 1 1 1 1 1 1 1
10*
245858 SEAT, valve 1 1 1 1 1 1 1
13‡
255275 HANDLE; includes trigger
guard and swivel
1 1 1 1 1
14
248952 HANDLE KIT 1 1
14a★ --- SWIVEL
15
276997 HANDLE SLEEVE,
insulated
1 1
16†
287449 TRIGGER KIT, 4-finger,
straight; includes 16c
1 1 1 1
287451 TRIGGER KIT, 4-finger,
curved; includes 16c
1
287450 TRIGGER KIT, 2-finger;
includes 16c
1 1
16c† 117602 SCREW, shoulder, #8-32 2 2 2 2 2 2 2
19
XHD001 GUARD, RAC tip 1 1 1 1 1 1
20
XHDxxx SWITCH, RAC tip; 519
size included
1 1 1 1
XHDxxx SWITCH, RAC tip; 529
size
1
20a✓
--- SEAL, fluid 1 1 1 1 1
20b✓
--- GASKET 1 1 1 1 1
20c
--- TIP, spray, XHD RAC 1 1 1 1 1
21*
179733 SEAL, sleeve 1 1 1 1 1 1 1
24
119740 O-RING 1 1
26
287032 FILTER, 60 mesh included
with gun
1 1 1 1 1 1
287034 FILTER, 60 mesh and 100
mesh combo
1 1 1 1 1 1
29▲
222385 CARD, medical alert (not
shown)
1 1 1 1 1 1 1
30
166969 GASKET 1
31 220251 GUARD, flat tip 1
32 163519 TIP, flat 1
--- Not for sale
▲ Replacement safety labels, tags, and cards are available at no cost.
* Parts included in Repair Kit 273141 purchased separately.
† Trigger kit (16) includes mounting hardware for either XTR5 or XTR7 gun.
‡ Handle is not pressure rated for use with the XTR 7. For an XTR 7, order handle 248952 and sleeve 276997 or 15E083
depending on your model.
✓ Included in OneSeal™ Repair Kit XHD010 (5 each per package, purchase separately).
★ Do not remove swivel. If the swivel needs to be replaced, order replacement handle kit 248952.
