Technical Specifications
22 3A7469D
Technical Specifications
California Proposition 65
XTR5+ and XTR7+, XTR7+ High Flow, and 17V677
US Metric
Maximum working pressure (XTR5+) 5000 psi 35 MPa, 345 bar
Maximum working pressure (XTR7+, XTR7+ High
Flow, 17V677)
7250 psi 50 MPa, 500 bar
Maximum fluid operating temperature 160°F 71°C
Noise (dBa)
Maximum sound pressure 84.3 dBa at 6000 psi (41 MPa, 414 bar)
Sound power 95.7 dBa at 6000 psi (41 MPa, 414 bar)
Sound pressure measured using the HD519 tip and water.
Sound power tested per ISO-9614-2.
Inlet/Outlet Sizes
Fluid inlet size 1/4 npsm (m) or 3/8 NPT
(XTR710 - XTR715, 17V677)
Fluid orifice size 0.090 in. 2.3 mm
Materials of Construction
Wetted materials on all models Aluminum, stainless steel, acetal,
polyethylene, nylon, polypropylene,
carbide, polyurethane, solvent-resistant
o-rings
Notes
All trademarks or registered trademarks are the property of their respective owners.
CALIFORNIA RESIDENTS
WARNING: Cancer and reproductive harm –
www.P65warnings.ca.gov.
