Graco XTR7+ XTR720 - Page 17

Parts
3A7469D 17
XTR7+ Parts List
Ref. Part Description
Quantity
XTR720 XTR721 XTR722 XTR723 XTR724 XTR725
1 19B238 BODY, gun 1 1 1 1 1 1
2* 245881 SEAL, retainer assembly 1 1 1 1 1 1
3* --- GASKET 1 1 1 1 1 1
4 19B239 CAP, end 1 1 1 1 1 1
5 117350 SPRING 1 1 1 1 1 1
6 15E088 RETAINER, needle 1 1 1 1 1 1
7 15E085 PIN, actuator 2 2 2 2 2 2
8* 18C010 NEEDLE 1 1 1 1 1 1
9* 156766 GASKET 1 1 1 1 1 1
10* 245858 SEAT, valve 1 1 1 1 1 1
14
248952 KIT, repair, handle 1 1 1 1 1 1
17V749 KIT, repair, handle
14a★ --- SWIVEL
14b 17G980 SWIVEL
15
276997 HANDLE SLEEVE, insulated 1 1
15E083 HANDLE SLEEVE, round 1 1 1 1
16
287449
TRIGGER KIT, 4-finger,
straight; includes 16a and 16b
1 1 1
287451
TRIGGER KIT, 4-finger,
curved; includes 16a and 16b
1
287450
TRIGGER KIT, 2-finger;
includes 16a and 16b
1 1
16a† 192272 PIN, pivot 1 1 1 1 1 1
16b† 203953 SCREW, cap, #10-24 1 1 1 1 1 1
19 XHD001 GUARD, RAC tip 1 1 1 1 1
20 XHDxxx
SWITCH, RAC tip; 519 size
included
1 1 1 1
SWITCH, RAC tip: 523 size
included
SWITCH, RAC tip: 531 size
included
20a✓ --- SEAL, fluid 1 1 1 1
20b✓ --- GASKET 1 1 1 1
20c --- TIP, spray, XHD RAC 1 1 1 1
21* 179733 SEAL, sleeve 1 1 1 1 1 1
24** 119740 O-RING 1 1 1 1 1 1
26
287032
FILTER, 60 mesh included
with gun
1 1 1 1 1 1
287034
FILTER, 60 mesh and 100
mesh combo
1 1 1 1 1 1
29▲ 222385
CARD, medical alert (not
shown)
1 1 1 1 1 1
30 166969 GASKET 1
