CONNECTING THE UNIT
● Swivel the cable winder out of the motor body. Do this by pulling on the slightly protruding
tab at the top.
● Remove the plug from the holder and unwind the cable to the desired length. You can secure
the cable in a recess provided for this purpose.
● Press the two outer walls together slightly and swivel the cable winder back into the motor
body.
● Insert the plug into the socket.
„click“
1. 2.
3. 4.
35
