4. Assembling the set-up kit
17 / 33
7. 8.
Place the upper shell with the scum wall on top of
the lower shell. Assemble the clamps for con-
necting the upper and lower shells.
Assemble the clamps for connecting the upper and
lower shells.
9. 10.
Drill the inflow and outflow with a DN 100 core
drill (with a diameter of 124 mm).
De-burr the hole. Insert the DN 100 lip seal. In the
case of the outflow, the direction of the feed-
through must be from the inside out. Affix the “Out-
flow” sticker.
11.
12.
Slide the outflow pipe through the outflow hole
from the inside.
The jack base must be turned depending on the
tank size. The specified tank size on the base must
be the same as on the jack.
2700 L 3750 L 4800 L 6500 L
145 mm 145 mm 190 mm 205 mm
H
