5. Assembling control unit one2clean in the interior
20 / 33
5. Assembling control unit one2clean in the interior
1. 2.
The control must be installed in a dry and dust-
free interior. Two 8 mm holes must be drilled
into the wall for assembly.
Secure the control to the wall using the dowels and
screws provided.
3. 4.
Position the compressor on the control. Connect
the compressor to the control unit pipe using the
90 Deg hose piece and hose clamps provided.
Plug the compressor plug into the control sock-
et.
Connect the air hoses to the control’s hose nozzles.
5.
For further information please refer to the Con-
trol Unit operating manual.
Note for one2clean plus control: Assembly of one2clean plus control similar to one2clean control.
