4. Assembling the set-up kit
19 / 33
19.
20.
The cord must be secured to the pipe aerator (6
mm hole). The air hose (19 mm) must be con-
nected on the opposite side. Systems for more
than 7 inhabitants have two pipe aerators.
Position the pipe aerator(s) on the bottom of the
tank. It must be slid under the scum board such that
even the first chamber is ventilated. To attach the
cord, a hook is fitted inside the tank dome. The hole
for the hook should be pre-drilled with a 4mm bit.
21.
22.
In systems with two pipe aerators, use a Y-
piece to join the hoses of the two pipe aerators.
Assemble the tank dome according to the installation
instructions (seal!).
23. 24.
Secure the sampling tank to the tank dome with
a Spax screw.
Connect the air hose (13 mm) to the in-feed jack.
