5
press the “Print/Send/Data” pushbutton.
The release date of the software will be
displayed. A display of “07.15.97” would
correspond to July 15, 1997. This is provided
as a reference aid in determining which
features are contained within the software.
3. Press the “Print/Send/Data” pushbutton.
The scale will display “SCALE”. Press the
“Print/Send/Data” pushbutton again; the
model number of the scale will be displayed
“4802”. This is provided as a reference aid
to help with customer trouble-shooting and is
set at the factory.
4. Press the “Print/Send/Data” pushbutton.
The scale will display “AutOFF” (automatic
shut-off time). Again press the
“Print/Send/Data” pushbutton. The
currently selected number of seconds before
the scale shuts-off will be displayed. This is
normally set at the factory to be 90 seconds.
It can be altered in 15 second increments
from 15 seconds to 180 seconds (3 minutes).
An additional “Cont” (continuous) option is
provided for some special applications; this
prevents the scale from automatically
shutting-off; the scale can then only be
turned off by pressing and holding the “ON /
(OFF) / ZERO” pushbutton. Use of the
continuous mode of operation is not
recommended since it will discharge the
battery if the operator forgets to deliberately
turn the scale “off”.
To alter the length of the automatic shut-off
time press the “RECALL PRIOR WEIGHT”
pushbutton. The automatic shut-off time will
advance through the available options. Stop
at the desired time interval.
5. Press the “Print/Send/Data” pushbutton.
The scale will display “AC con” (AC power
continuous operation). This feature is used
in the model 4802 PEDIATRIC SCALE to
cause the scale to remain “on” as long as AC
power is provided (automatic shut-off will not
occur. Pressing the “Print/Send/Data”
pushbutton again will show this option
selected as “On” or “OFF”. To alter the
selection, press the “RECALL PRIOR
WEIGHT” pushbutton.
6. Press “Print/Send/Data” pushbutton. The
scale will display “UnitS” (weight units).
This is the start of the various weight units
(kilograms, pounds, ounces, pounds/ounces)
that can be selected. Use the “RECALL
PRIOR WEIGHT” pushbutton to set each
weight unit “On” or “OFF”. NOTE: If all the
units are set to “OFF” the scale will
automatically default to “KILOS”.
7. Press the “Print/Send/Data” pushbutton
again. The “KILOS” annunciator will light
and the display will show “On” or “OFF”.
Setting this to “On” will allow display of the
weight in kilograms with a display of “0.000”.
Normal setting as shipped from the factory is
“On”.
8. Press the “Print/Send/Data” pushbutton
again. The “POUNDS” and “OUNCES”
annunciators will light and the display will
show “On” or “OFF”. Setting this to “On”
will allow display of “0” (pounds) 0.0
(ounces)”. Normal setting as shipped from
the factory is “On”.
9. Press the “Print/Send/Data” pushbutton
again. The “POUNDS” annunciator will light
and the display will show “On” or “OFF”.
Setting this to “On” will allow display of the
weight in pounds with a display of “0.000”.
Normal setting as shipped from the factory is
"OFF”.
10. Press the “Print/Send/Data” pushbutton
again. The “OUNCES” annunciator will light
and the display will show “On” or “OFF”.
Setting this to “On” will allow display of the
weight in ounces with a display of “0.00”.
Normal setting as shipped from the factory is
“OFF”.
11. Press the “Print/Send/Data” pushbutton.
The scale will display “bEEPEr” (audio
beeper). Press the “Print/Send/Data”
pushbutton again. “On” or “OFF” will be
displayed. This may be changed by pressing
the “RECALL PRIOR WEIGHT” pushbutton.
Setting this option to “OFF” will eliminate the
audible signal that occurs when a front panel
pushbutton is pressed or a weight is locked in
Normal setting as shipped from the factory is
“On”.
12. Press the “Print/Send/Data” pushbutton. If
equipped at the factory with the data port the
scale will display “rS-232”, indicating the
start of the serial data port options. Separate
detailed instructions for this feature are
available from the factory. Call us at
