Seat functions and operation
24
Fore/aft adjustment
The fore/aft adjustment is released by lifting
the locking lever.
WARNING. Risk of accident!
Do not operate the locking lever
while driving.
After the adjustment, the locking lever
must latch into the desired position with an
audible click. It should not be possible to
move the driver's seat into another position
Do not lift the locking lever with your
leg or calf.
Seat pan angle adjustment *
The angle of the seat pan can be individually
adjusted.
To adjust the angle of the seat pan, pull the
left handle upwards. By exerting pressure on
or off the front or rear part of the seat pan it
can be moved to the desired position.
Seat depth adjustment *
The depth of the seat pan can be individually
adjusted.
To adjust the depth of the seat cushion, pull
the right handle upwards. By moving the seat
cushion backwards or forwards the desired
seating position can be reached.
* if fitted ** depending on model *** optional extra
