Seat functions and operation
26
Backrest extension * ***
The backrest extension can be individually
adjusted for height by pulling it upwards over
the various increments up the end stop.
To remove the backrest extension, pull it
upwards over the end stop.
Lumbar support
By turning the adjustment knob to the left or
right, both the height and curvature of the
backrest cushi
on can be individually adjusted.
This increases both the seating comfort and
the performance of the driver.
Backrest adjustment **
Pull up the locking lever to release the
backrest catch. When releasing the backrest
catch, do not apply load to the backrest by
pressing against it.
By exerting pressure on or off the front or rear
part of the seat pan it can be moved to the
desired position. Release the locking lever to
lock the backrest.
It should not be possible to move the
backrest into another position after it has
been locked.
When the backrest is folded forward,
fluted metal locking devices on either side –
left and/or right – protrude from the bottom of
the backrest and, during the adjustment
procedure, can cause shearing and crushing
of the body of the person performing this task.
– DO NOT REACH INTO THIS DANGER
ZONE –
* if fitted ** depending on model *** optional extra
