FIRMWARE VERSION 1.0.6.11 GXP2120/GXP2110/GXP2100/GXP14xx USER MANUAL Page 65 of 81
it will call the configured Speed Dial number using account 2.
 Dial DTMF
Enter a series of DTMF digits in the Value field to be dialed during
the call. "Enable MPK Sending DTMF" has to be set to "Yes" first.
 Voice Mail
Select Account and enter the Voice Mail access number in the Value
field.
 Call Return
The last answered calls can be dialed out by using Call Return. The
Value field should be left blank. Also, this option is not binding to the
account and the call will be returned based on the account with the
last answered call.
 Transfer
Select Account, and enter the number in the Value field to be
transferred (blind transfer) during the call.
 Call Park
Select Account, and enter the call park extension in the Value field to
park/pick up the call.
 Intercom
Select Account, and enter the extension number in the Value field to
do the intercom.
 LDAP Search
This option is to narrow the LDAP search scope. Enter the LDAP
search base in the Name field. It could be the same or different from
the Base in LDAP configuration under Advanced Settings. The Base
in LDAP configuration will be used if the Name field is left blank.
Enter the LDAP Name/Number filter in the Value field.
NETWORK PAGE DEFINITIONS
Network -> Basic Settings
Internet Protocol
Selects Prefer IPv4 or Prefer IPv6.
IPv4 Address Type
Allows users to configure the appropriate network settings on the phone to
obtain IPv4 address. Users could select "DHCP", "Static IP" or "PPPoE". By
default, it is set to "DHCP".
DHCP Host name
(Option 12)
Specifies the name of the client. This field is optional but may be required by
some Internet Service Providers.
DHCP Vendor Class ID
(Option 60)
Used by clients and servers to exchange vendor class ID.
