Grandstream Networks GXP2160 - Welcome and Product Overview

5 6
Note: For the detailed user manual, please download from:
http://www.grandstream.com/support
Tips For Using the Keypad:
PHONE CONFIGURATION:
Congure the GXP2160 using Web Browser:
1. To access the MENU, press the round MENU button.
2. Navigate the menu by using the UP/DOWN and LEFT/RIGHT buttons.
3. Press the round MENU button to conrm a menu selection.
4. The phone automatically exits MENU mode with an incoming call, the phone
goes off-hook or the MENU mode is left idle for 60 seconds.
1. Ensure your phone is powered up and connected to the Internet.
2. Press the UP button to see the IP address.
3. Type the phone’s IP address in your PC browser (See gure on right).
4. The default administrator username and password are “admin”; the default end-
user username is “user“ and the password is “123”.
Congure the GXP2160 using the Keypad:
1. Make sure the phone is idle.
2. Press the MENU button to access the keypad MENU to congure the phone.
3. Select MENU-> Phone-> SIP-> Account to congure settings for SIP Proxy,
Outbound Proxy, SIP User ID, SIP Auth ID and SIP Password.
4. Follow MENU options to congure the basic features of the phone. For ex-
ample: the IP address if using a static IP. For details, please check GXP2160
User Manual.
5. Please contact your ITSP (Internet Telephony Service Provider) for additional
settings that may be necessary to congure the phone.
Line keys
Soft keys
Message Waiting
Indicator
Multi-Purpose
keys
Message
Contacts
Transfer
Hold
Headset
Conference
Mute
Menu/OK Key
Standard Keypad
Navigation keys
Send
Volume
Speaker
