Grandstream Networks GXV3370 Administration Guide

GXV3370 Administration Guide
Version 1.0.1.12
P a g e | 59
add the number 2 on the port of the listening address. Reboot the phone
to make changes take effect.
The valid IP address range is from 224.0.0.0 to 239.255.255.255. Users
may also fill the label for each listening address corresponding to priority.
System Settings Page Definitions
System Settings/Ethernet Settings
Network Settings
Preferred Internet
Protocol
If IPv4 is selected, the phone will be using IPv4 addressing, otherwise, it
will be using IPv6 addressing. Default is Prefer IPv4.
Different Networks for
Data and VoIP Calls
If set to yes different configuration can be set for Data and VoIP calls.
IPv4
IPv4 Address Type
Configures the appropriate network settings on the phone. Users could
select from "DHCP", "Static IP" or "PPPoE"(Point-to-point Protocol over
Ethernet). By default, it is set to "DHCP".
DHCP VLAN Override
Selects the DHCP Option VLAN mode. When set to "DHCP Option 132
and DHCP option 133", the phone will get DHCP option 132 and 133 as
VLAN ID and VLAN priority. When set to "Encapsulated in DHCP Option
43", the phone will get values from Option 43 which encapsulate VLAN ID
and VLAN priority.
Note: Please make sure the "Allow DHCP Option 43 and Option 66 to
Override Server" setting under maintenance→upgrade is checked. The
default setting is " Encapsulated in DHCP Option 43 ".
DHCP Host name
(Option 12)
Sets the name of the client in the DHCP request. It is optional but may be
required by some Internet Service Providers.
DHCP Vendor Class ID
(Option 60)
Configures the vendor class ID header in the DHCP request.
The default setting is Grandstream GXV3370.
IP Address
Defines the phone’s static IP address if the static IP is used.
Subnet Mask
Determines the network’s subnet mask if the static IP is used.
Default Gateway
Defines the network’s gateway address if the static IP is used.
DNS Server 1
Configures the primary DNS IP address if the static IP is used.
DNS Server 2
Configures the secondary DNS IP address if the static IP is used.
PPPoE Account ID
Configures the PPPoE account ID if the PPPoE is used.
PPPoE Password
Sets the PPPoE password if the PPPoE is used.
Layer 2 QoS
802.1Q/VLAN Tag
(Ethernet)
Assigns the VLAN Tag of the Layer 2 QoS packets for Ethernet.
The Default value is 0.
