GXV3370 Administration Guide
Version 1.0.1.12
Configures the UserID for the corresponding VPK mode when the accounts
being configured as VPK.
When key mode is set to Dial DTMF it Configures the dialed DTMF content.
When key mode is set to Multicast Paging, it configures the multiple
broadcast address.
Displays account name if configured, otherwise, displays “Account X”
where X is the account number.
Configures the prefix prepended to the BLF extension if the phone answers
a call to the monitored party by the BLF key. Default setting is ** for each
account.
Determines the event list BLF URI on the phone to monitor the extensions
in the list with MPK keys. This feature is based on BroadSoft standard. It
requires filling in the BLF ID to the box.
For example, if the server provides the URI: BLF123@myserver.com, this
field should be filled with BLF123. Then the monitored extensions will be
populated in the MPK app or Extension Board (if supported).
Force BLF Call-pickup
by Prefix
Uses the prefix for BLF Call-pickup. The default setting is “No”.
System Application/Contacts
Sets which part of name, first name or last name, will be sorted in
alphabetical order to display.
Controls the behaviors of the phonebook key. It could be set to:
• Default
• LDAP Search
• Local Phonebook
• Local Group
• Keep
The default setting is “Default”, which set the phonebook key to the
Contacts menu.
Configures the emergency contact in logout mode. If the system is logout,
guest users can dial the configured emergency contacts.
Input the number in the input box and click "Add" to add the number to the
contacts list. To delete the existing ICE number, select the number in the
contacts list and click "Delete".
