Grant 20 Series User Manual

29486 Version 1 - December 2009
Page 17
www.grant.co.uk
6. Setting Up a Direct Connection to PC
Prerequisites
Before proceeding with the installation you will require the following.
- A 20xx Data Logger with wireless Ethernet and external Power Supply
- A wireless connection on a laptop or PC
6.1 Configuring the Wi-Fi connection
Attach the logger to the PC via USB and click on the Communication Wizard button in the
SquirrelView software..
Choose the Ethernet (wired / wireless) option and click Next.

Grant 20 Series Specifications

General

Series	Grant 20 Series
Operating Temperature	-20°C to +70°C
Digital Outputs	Up to 4
Logging Rate	1 second to 12 hours
Connectivity	USB
Measurement Parameters	Temperature, Humidity, Voltage, Current
Temperature Range	-40°C to +85°C
Humidity Range	0% to 100% RH
Resolution	0.1°C
Dimensions	150 x 80 x 35 mm
