SPECIFICATIONS (CONT.)
Mechanical Specifications
Component Depth Width Height Weight Rack Units
Control Panels Flat Support Structure Orientation
KAYN-PNL-100-15* 356.4 mm (14.03 in.) 758.3 mm (29.85 in.) 84.3 mm (3.32 in.) 14.5 kg (32.0 lbs.) n/a
KAYN-PNL-200-25 488.4 mm (19.23 in.) 1341.7 mm (52.82 in.) 84.3 mm (3.32 in.) 29.9 kg (65.8 lbs.) n/a
KAYN-PNL-200-35 488.4 mm (19.23 in.) 1533.7 mm (60.38 in.) 84.3 mm (3.32 in.) n/a
KAYN-PNL-300-25 637.1 mm (25.08 in.) 1341.7 mm (52.82 in.) 84.3 mm (3.32 in.) n/a
KAYN-PNL-300-35 637.1 mm (25.08 in.) 1533.7 mm (60.38 in.) 84.3 mm (3.32 in.) 44.7 kg (98.4 lbs.) n/a
KAYN-PNL-400-25 746.3 mm (29.38 in.) 1341.7 mm (52.82 in.) 84.3 mm (3.32 in.) n/a
KAYN-PNL-400-35 746.3 mm (29.38 in.) 1533.7 mm (60.38 in.) 84.3 mm (3.32 in.) 57.3 kg (126.2 lbs.) n/a
KAYN-PNL-AUX-25 185.7 mm (7.31 in.) 621.7 mm (24.48 in.) 84.3 mm (3.32 in.) 6.1 kg (13.4 lbs.) n/a
KAYN-PNL-AUX-35 185.7 mm (7.31 in.) 813.7 mm (32.04 in.) 84.3 mm (3.32 in.) 6.3 kg (13.8 lbs.) n/a
KAYN-PNL-MENU 91.7 mm (3.61 in.) 417.85 mm (16.45 in.) 270.10 mm (10.63 in.) 6.2 kg (13.5 lbs) n/a
Frames
KAYN-FRM-250C 546.10 mm (21.5 in.) 482.60 mm (19 in.) 177.80 mm (7 in.) 17.69 kg (39 lbs.) 4
KAYN-FRM-450 522.73 mm (20.58 in.) 482.60 mm (19 in.) 441.96 mm (17.4 in.) 30.39 kg (67 lbs.) 8
PCU
KAYN-PNL-PCU 588.52 mm (23.17 in.) 482.60 mm (19 in.) 132.59 mm (5.22 in) 16.06 kg (35.4 lbs.) 3
*w/o Local Aux module.
