Grasshopper 718D User Manual

43
1994 SUPPLEMENT
Figure 42
MODEL 718K and 720K - Starting Circuit.
(Kohler Command engines)
-
+
IN START POSITION
BU
BU
BU
YE
GR
RD
PTO OFF
STEERING LEVERS OU
T
STARTER
NC
NO
SEAT
IN-LINE
FUSEHOLDER
START FUSE
STARTER
RELAY
BRAKE
SWITCH
PTO
SWITCH
LEFT
STEER
RIGHT
STEER
DIODE ALLOWS ENGINE
TO CRANK WITH
BRAKE SWITCH ON OR OFF
KEY
SWITCH
LT
STR
RT
STR
DRIVER
ON SEAT
SEAT
SWITCH
YE
YE
YE
YE
M
B
S
G
L
Figure 43
MODEL 721, 721D and 725 - Starting Circuit.
(All Kubota engines)
+
-
AC
50
19
30
17
BU
YE
RD
GR
STARTER
IN START POSITION PTO OFF STEERING LEVERS OUT
START FUSE
RELAY B
PTO
SWITCH
LEFT
STEER
RIGHT
STEER
KEY
SWITCH
LT
STR
RT
STR
YE
YE
BU
BU
BU
Serial numbers of 340725 and higher,
refer to page 24 for troubleshooting.
Serial numbers of 340725 and higher,
refer to page 28 for troubleshooting.
