8
5. RECEIVER
Servo socket
Channel 1 ~ Channel 6
Telemetry
Channel 5
Servo socket
Programming
socket
Programming
socket
Servo socket
33505 GR-12S HoTT
Servo secket
: Channel 7-12,15~16
Battery socket : B
Battery socket : B
Battery socket : B
Telemetry socket : T
Servo socket
: Channel 1~6, 13~14
Battery socket : B
Sum signal socket : S
S1023 GR-32L DUAL HoTT
S1022 GR-24L HoTT
S1021 GR-16L HoTT
