GRAUPNER GR-12 User Manual

7 / 24
33506_33508_33512_33516_T1V2sh
GR-24
Antenna
2x cable 145 mm,
of which last 30 mm active
Operating voltage (2.5) 3.6 ... 8.4 V
Frequency range 2400 ... 2483.5 MHz
Modulation 2.4 GHz FHSS
Number of controls 12
Current consump-
tion approx.
70 mAh
Temperature range -15 … +70°C
Dimensions approx. 46 x 31 x 14 mm
Weight approx. 16 g
GR-32
Antenna
2x cable 145 mm,
of which last 30 mm active
Operating voltage (2.5) 3.6 ... 8.4 V
Frequency range 2400 ... 2483.5 MHz
Modulation 2.4 GHz FHSS
Number of controls 16
Current consump-
tion approx.
140 mAh
Temperature range -15 … +70°C
Dimensions approx. 63 x 30 x 14 mm
Weight approx. 24 g
Connection table
Updates
and
telemetry
SUMDIN CH OUTPUT
TYPE
(Sum signal
etc.)
Optional
voltage
measure-
ment
GR-12 CH5 – CH6 CH6
GR-16 T CH7 CH8 CH6
GR-24 T CH7 CH8 –
GR-32 T CH7 S –

GRAUPNER GR-12 Specifications

General

Channels	6
Frequency	2.4 GHz
Weight	7 g
Telemetry	Yes
Modulation	HoTT
Operating Voltage	3.6V - 8.4V
