Technical data
Antenna
2x 145 mm,
of which the last 30 mm active
Operating voltage 4 ... 10 V
Frequency range 2400 ... 2483.5 MHz
Modulation 2.4 GHz FHSS
Current consumption approx. 70 mA
Temperature range -15 … +70°C
Dimensions approx.
S1045: 25 x 25 x 4 mm
S1046: 25 x 15 x 4 mm
Weight approx. 4 g
Attachment
Hole diameter: 3,2 mm
Hole distance: 20 mm
Symbol description
Always observe the information indicated by these warning signs.
Particularly those which are additionally marked with the words
CAUTION or WARNING.
!
The signal word WARNING indicates the potential for serious injury,
the signal word CAUTION indicates possibility of lighter injuries.
The signal word Note indicates potential malfunctions.
Attention indicates potential damages to objects.
Safety notes
!
These safety instructions are intended not only to protect the prod-
uct, but also for your own and other people’s safety. Therefore please
read this section very carefully before using the product!
• Do not leave the packaging material lying around, this could be a
dangerous toy for children.
• Persons, including children, with reduced physical, sensory or
mental capabilities, or lack of experience or knowledge, or not
capable to use safely the receiver must not use the receiver with-
out supervision or instruction by a responsible person.

GRAUPNER GR-12L Specifications

General

Type	Radio-Controlled (RC) Model Parts
Proper use	Helicopter
Product type	Receiver
Programmable	Yes
Product color	Black, Green
Frequency range	2400 - 2483.5 MHz
Channels quantity	16 channels
Brand compatibility	Graupner
Maximum operating distance	3000 m
Voltage	3.6-8.4 V
Operating temperature (T-T)	-15 - 70 °C

Weight and Dimensions

Width	25 mm
Height	4 mm
Weight	4 g
