9 - 44
9.16 ELECTRICAL SYSTEM
Model 988085, 087, 088, 091, 309
1
2
3
4
5
1. Key Switch Assembly
2. Single Pole N.O. with Cover
3. Electrical Interlock Module
4. Neutral Start Switch
5. Neutral Start Switch (N.C.)
