19
DECK LIFT
Item Part No. Qty. Description
1 00456000 1 Lift, Mower
2 05707300 1 Ring, Retaining-External 1.00 x .078
3 05500123 2 Bushing 1.00 x 1.25 x 1.937
4 06608900 1 Key, Woodruff .25 x 1.00
5 06443000 1 Washer, Flat-Steel- 1.062 x 2.0 x .134
6 00441000 1 Mower, Lift Arm
7 00481600 1 Weldment, Rear Lift Arm-Left Hand
8 05518400 4 Bushing, Flange-Nylon .762 x 1.0 x .580 x 1.48
9 06413400 2 Washer, Hardened-Steel .758 x 1.23 x .031
10 05714600 2 Ring, Retaining-External .689 x .077
11 00481500 1 Weldment, Rear Lift Arm- Right Hand
12 04063000 2 Rod, Lift Assist 16.35"
13 05800700 8 Pin, Roll .250 x 1.25
14 06436100 4 Washer, Flat-Steel .630 x 1.005 x .062
15 02950253 1 Weldment, Mower Frame 50/60
16 05968700 5 Bolt, Hex .62-11 x 1.50 Grade 5
17 06540700 5 Nut, Locking-Nylon .625-11
PF3701
1
2
3
4
5
6
7
8
9
10
8
8
11
8
9
12
12
13
13
13
13
3
15
16
17
16
14
14
To Next Page
