Gravely ZT X User Manual

EN - 9
REQUIRED TOOLS
• 1/2", 3/8" 7/16" and 9/16" wrench and/or
adjustable wrench
UNPACK UNIT
1. Disengage transaxles. See Move Unit
Manually on page 18.
2. Disengage parking brake. See Parking
Brake Lever on page 16.
3. Move unit from container to a level
surface.
4. Engage parking brake. See Parking
Brake Lever on page 16.
5. Engage transaxles. See Move Unit
Manually on page 18.
6. Cut all packaging cable ties on unit and
discard.
7. Remove packaging material from unit and
discard.
SECURE SEAT CABLE
1. Remove nut and one end of seat cable.
Reinstall nut to secure remaining cable
end to seat plate.
See Figure 3.
2. Remove nut from bolt on battery tray.
Retain nut.
See Figure 4.
See Figure 5.
3. Tilt seat up slightly so cable end reaches
bolt on battery tray.
4. Install cable end onto bolt on battery tray
and secure with nut removed in step
2.
5. Models 915255, 915256, 915257 Only:
Reposition seat.
See Reposition Seat
And Connect Switch on page 10.
ASSEMBLY
Figure 3
Figure 4
Figure 5

Gravely ZT X Specifications

General

Engine Brand	Kawasaki
Engine Displacement	726 cc
Fuel Capacity	3.5 gallons
Deck Material	Steel
Seat Type	High back
Spindle Material	Aluminum
Turning Radius	Zero-turn
Warranty	3 years
Cutting Height	1.5 - 4.5 inches
Engine Power	21.5 HP
