The damages to the radio caused due to
static electricity are as follows:
1. Garbled buttons with abnormal display;
2. Significant performance decline in
reception of FM signals.
1. Frequency range:
FM: 87.5-108MHZ AM: 520-1710 kHz
2. Noise-limited sensitivity:
FM: 30dB, higher than 6μV in the noise-limited
sensitivity
AM: 20dB, higher than 3mV in the noise-limited
sensitivity
WB: 30dB, higher than 6μV in the noise-limited
sensitivity
3. Signal to noise ratio:
FM: 98MHz≥45dBμ
AM: 990KHz≥40dBμ
4. Max. current consumption: ≤150mA
5. Max. output power: ≥ 90mW
6. Max. distortion: ≤5%
7. Loudspeaker specification: Φ30MM 12Ω 0.5W
8. Input voltage: DC-3V (AAA*2)
9. Overall dimension: 16.2 X 55.9 X 109mm
10. Net weight: 65g
Technical Indicators
