❏ 1. Trim the excess material from the aft edge of the
molded plastic cowl. Cut a hole in the middle for the prop
shaft, then cut a slot for the nose gear.
❏ 2. Mount the cowl to the fuse with tape. Any kind of tape
will do, but we used 1/4" red striping tape. Mount the prop
adapter and prop to the gearbox. Note: If you are not able
to tighten the prop nut because the drive washer keeps
turning, remove the prop adapter assembly from the
gearbox. Tighten the prop to the adapter off of the gearbox.
Loosen the prop and separate the drive washer from the
adapter. Rejoin the assembly to the gearbox and tighten.
Final Assembly
26
