2. Productfeatures
For car manufactured in Japan equipped with12V battery.
Simultaneous display with a maximum of 3 items. Analogue and digital dis-
plays integrating 7 data.
7 displaying data are boost, water temperature, oil temperature, oil pressure,
fuel pressure, exhaust temperature, and power voltage.
There are two gauge faces for boost and oil. Optimum for turbo engine as
well as NA engine.
The power unit can be installed inside of the engine room with simple water-
proof. Only one harness line pulled in the car so no need to pull several
extra harness lines.
Analogue meter is viewability considered: 270-degree view.
Backlight with super luminosity LED lasts almost forever. In addition, the
selectable backlight colors are white, green, red, blue, orange, purple, and
light blue.
Illumi interlocking switch is capable of dimming.
All settings and changes can be performed by the remote controller. Easy
settings with user-friendly icons and buttons.
Peak value memory and warning function are configurable respectively.
Performs IG key Opening/Ending demo on both analogue/digital displays.
Caution
Attention
For the technician
For the user
Installation involves disassembly operations: inner-outer covering parts of a vehicle and modification of electrical component. Please
operate carefully since we don’t have any responsibility of these operations.
Make sure not to do miswiring and short. Could lead to the wreckage of all electrical components.
Do not modify the sensor cord. Could lead to a short or bad connection as well as the crash of all electrical components.
Provide insulation by vinyl tape for soldered areas.
Pressure sensor is a precision component and fragile. Do not install near vibrating place, water, and under high temperature condition.
When drilling halls for the installation of exhaust temperature sensor, do not leave debris of cutting in the pipe.
Do not install the power unit near the place with humid and dust, exposed to direct light, nozzle of heater, etc.
Do not disassemble the product. It will be exempt from warranty.
Do not install in electrically noisy environments such as ignite signal area. Could lead to the sensor glitch.
When removing the minus terminal on the battery, there are things that lose memory: clock, audio, navigation system, electric seat.
Read the instruction carefully before operation. After the operation finished, reconfigure settings according to instruction.
Due to the precision mechanical equipment, do not drop or hit it hard.
Soon after purchase, check all parts included as specified on the page 3 (Complete parts).
Please contact us if you see the different numbers between the meter and power unit.
Wipe with a dried cloth when you clean. When seeing the spots, wipe with a damp and tightly wrung out cloth.
Should you have questions or concerns about our product,do not hesitate to contact us.
Please pass this manual and warranty to others when renting out or transferring your vehicle possession.
Please return this manual with warranty to the customer when mounting is finished.
