GReddy Multi D/A Gauge User Manual

7.Troubleshooting
・ Indicating lower value.
・ With ignition on, the pointer
is not at zero.
・ With ignition off, the pointer
doesn’t come back at zero.
・ No ending demo.
・“Warning action” outside
the preset value.
・ Pointing strange value.
・ With power on, the pointer
doesn’t function.
Symptom
・ Grounding wire is not on the minus terminal
on the battery.
・ Miswiring.
SolutionCause
・ Picking up noise from ignition signal or other
signals.
・ Wiring is short circuit.
・ Wiring is disconnected or break.
・ Sensor harness’s coupler is connected
mistakenly.
・ Power source and ignition power source
are not connected each other.
・ Extend the black line from the power source
and connect to the minus terminal.
・ Please refer to “4 Installation” and rewire
them.
・ Avoid noise occurring areas and reinstall
sensor harness.
・ Check if any damage on wire and if it is
touching car body or not.
・ Check if the coupler is disconnected or
the wire is damaged.
・ Check if the coupler is installed properly.
・ Wire power source and ignition power
separately.
Please refer to the following troubleshooting advices.
8. Service after the sales
Pleasedon'thesitatetoinformusifthereisanythingunclear.
Ifyoufinddifferentmanufacturingnumbersbetweenmeterandpowerunit,
pleasebringittotheplaceyoupurchasedorletusknowdirectly.
MultiD/AGaugeiswarrantedforoneyearfromthedateofpurchaseagainst
manufacturerdefects.Coverageisvalidonlywithproofofpurchasefroman
AuthorizedDealer.Alterationofthisproductwillvoidwarranty.
Additionalservicesareavailableforanominalcharge.

GReddy Multi D/A Gauge Specifications

General

Brand	GReddy
Model	Multi D/A Gauge
Category	Automobile Accessories
Language	English
