GREE GMV5E DC INVERTER VRF UNITS SERVICE MANUAL
46
Total rated capacity of outdoor modules
(multi-modular system)
Pipe between ODU and the first branch of IDU
Gas Pipe(mm)
Liquid Pipe(mm)
GMV-960WM/E-X
Φ31.8
Φ19.05
GMV-1010WM/E-X
Φ38.1
Φ19.05
GMV-1065WM/E-X
Φ38.1
Φ19.05
GMV-1130WM/E-X
Φ38.1
Φ19.05
GMV-1180WM/E-X
Φ38.1
Φ19.05
GMV-1235WM/E-X
Φ38.1
Φ19.05
GMV-1300WM/E-X
Φ38.1
Φ19.05
GMV-1350WM/E-X
Φ38.1
Φ19.05
GMV-1410WM/E-X
Φ41.3
Φ19.05
GMV-1460WM/E-X
Φ41.3
Φ19.05
GMV-1515WM/E-X
Φ41.3
Φ19.05
GMV-1580WM/E-X
Φ41.3
Φ19.05
GMV-1630WM/E-X
Φ41.3
Φ19.05
GMV-1685WM/E-X
Φ41.3
Φ19.05
GMV-1750WM/E-X
Φ41.3
Φ19.05
GMV-1800WM/E-X
Φ41.3
Φ19.05
GMV-1845WM/E-X
Φ41.3
Φ19.05
GMV-1908WM/E-X
Φ44.5
Φ22.2
GMV-1962WM/E-X
Φ44.5
Φ22.2
GMV-2016WM/E-X
Φ44.5
Φ22.2
GMV-2072WM/E-X
Φ44.5
Φ22.2
GMV-2128WM/E-X
Φ44.5
Φ22.2
GMV-2184WM/E-X
Φ44.5
Φ22.2
GMV-2240WM/E-X
Φ44.5
Φ22.2
GMV-2295WM/E-X
Φ44.5
Φ22.2
GMV-2350WM/E-X
Φ44.5
Φ22.2
GMV-2405WM/E-X
Φ44.5
Φ22.2
GMV-2460WM/E-X
Φ44.5
Φ22.2
