Gree GMV-400WM/B-X - Page 222

GMV5 DC INVERTER VRF UNITS SERVICE MANUAL
219
Parts List:
No.
Name of part
GMV-224WM/B-X
GMV-280WM/B-X
Product Code
CN851W1280
Product Code
CN851W1290
Part code
Quantity
Part code
Quantity
1
Rear Grill
01574105
1
01574105
1
2
Top Cover
01264230
1
01264230
1
3
Diversion Circle
10474100
1
10474100
1
4
Fan motor Sub-Assy
15404605
1
15404605
1
5
Axial Flow Fan Sub-Assy
10338702
1
10338702
1
6
Fan Motor
15704124
1
15704124
1
7
Motor Support Sub-Assy
01804771P
1
01804771P
1
8
Gas By-pass Sub-Assy
04224100129
1
04224100129
1
9
Magnet Coil
4304000425
1
4304000425
1
10
Filter
07415200002
1
07415200002
1
11
Electromagnetic Valve
43000054
1
43000054
1
12
Top Cover
01264231P
2
01264231P
2
13
Rear Grill
01576013
1
01576013
1
14
Condenser Assy
0112431001
1
0112431001
1
15
Low Pressure Survey Valve
Sub-Assy
07334100026
1
07334100026
1
16
Cut-off Valve 1/4
07130239
1
07130239
1
17
Throttle Assy
05374100006
1
05374100006
1
18
Dry Filter Sub-Assy
07314100001
1
07314100001
1
19
Gas Tube Filter
072190511
1
072190511
1
20
Dry Filter
07218769
1
07218769
1
21
Cut-off Valve 3/8
07334100011
1
07334100011
1
22
Electronic Expansion Valve
Coil
4304413206
1
4304413206
1
23
Electronic Expansion Valve
07334390
1
07334390
1
24
Discharge Valve
07334100002
1
07334100002
1
25
Electronic Expansion Valve
Coil
4304413204
1
4304413204
1
26
Plate-type Heat Exchanger
00904100005
1
00904100005
1
27
Electronic Expansion Valve
07334412
1
07334412
1
28
One way Valve
04324001
1
04324001
1
29
Bidirectional Filter
07210044
1
07210044
1
30
Electronic Expansion Valve
Sub-Assy
07334100030
1
07334100030
1
31
Left Side Plate
01314712P
1
01314712P
1
32
Chassis Sub-assy
01194708
1
01194708
1
33
Gas-liquid Separator
07424188
1
07424188
1
34
Base Frame Assy
01284711
1
01284711
1
35
Oil Separator
0742418601
1
0742418601
1
36
Electrical Heater(Compressor)
7651873209
1
7651873209
1
37
Compressor and Fittings
00204100002
1
00204100002
1
38
Electric Heater(Compressor)
7651540713
1
7651540713
1
39
Magnet Coil
4304000423
1
4304000423
1
40
Magnet Coil
4304000415
1
4304000415
1
41
Gas Tube Filter
072190511
1
072190511
1
42
Cut-off Valve
07334100011
1
07334100011
1
