GREE GMV5 INDOOR UNIT SERVICE MANUAL
216
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-ND28TD/A-T
CM502N0100
GMV-ND36TD/A-T
CM502N0110
Part code
Quantity
Part code
Quantity
15
Brushless DC Motor
1501214301
1
1501214301
1
16
Strainer
0741410000601
1
0741410000601
1
17
Electronic Expansion Valve
07334492
1
07334492
1
18
Filter
07415210
1
07415210
1
19
Evaporator Assy
0102410009501
1
0102410009501
1
20
Water Tray Sub-Assy
01284100011
1
01284100011
1
21
Cross Flow Fan
10454100001
1
10454100001
1
22
Helicoid Tongue sub-assy
02224100007
1
02224100007
1
23
O-Gasket of Cross Fan
Bearing
76512203
1
76512203
1
24
Chassis Assy
01194100007
1
01194100007
1
25
Left Side Plate Sub-Assy
01314100022
1
01314100022
1
Above data is subject to change without notice, pls reference the SP in global service website.
No.
Name of part
For the following unit
For the following unit
Unit
Product Code
Unit
Product Code
GMV-ND45TD/A-T
CM502N0120
GMV-ND50TD/A-T
CM502N0130
Part code
Quantity
Part code
Quantity
1
Remote Controller
3051012902
1
3051012902
1
2
Drain Hose Sub-Assy
05232050
1
05232050
1
3
Temperature Sensor
39008000079G
1
39008000079G
1
4
Water Level Switch
4501270301
1
4501270301
1
5
Water Pump Assy
15404100005
1
15404100005
1
6
Pump Drainpipe
26905288
1
26905288
1
7
Water Pump
43138220
1
43138220
1
8
Hook
02112466
4
02112466
4
9
Right Side Plate Sub-Assy
01314100023
1
01314100023
1
10
Tube Exit Plate Assy
01344100020
1
01344100020
1
11
Electric Box Assy
01394100396
1
01394100396
1
12
Main Board
30226000029
1
30226000029
1
13
Terminal Board
4201026603
1
4201026603
1
14
Terminal Board
4201800002601
1
4201800002601
1
15
Brushless DC Motor
1501214301
1
1501214301
1
16
Strainer
0741410000601
1
0741410000601
1
17
Electronic Expansion Valve
07334494
1
07334494
1
18
Filter
07415210
1
07415210
1
19
Evaporator Assy
01024100014
1
01024100014
1
20
Water Tray Sub-Assy
01284100011
1
01284100011
1
21
Cross Flow Fan
10454100001
1
10454100001
1
