GREE GMV5 INDOOR UNIT SERVICE MANUAL
223
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND112ZD/A-T
CM600N0380
GMV-ND125ZD/A-T
CM600N0390
GMV-ND140ZD/A-T
CM600N0340
GMV-ND160ZD/A-T
CM600N0500
Part code
Quantity
5
Connection Board
02229406
1
6
Right Cover Plate
26909422
1
7
Installation Supporting Frame
01809402
1
8
Right Side Plate Sub-Assy
01319408
1
9
Right Foam Assy
12509425
1
10
Axile Bush
10542704
2
11
Plate Board of Water Releasing Flume
26909442
1
12
Water Releasing Flume
26909441
1
13
connected board (evaporator)
01344108
1
14
Strainer
0741410000601
2
15
Electronic Expansion Valve
07334468
1
16
Electric expand valve fitting
4304413203
1
17
Rotating Shaft
26909430
6
18
Supporter
26909409
3
19
Evaporator Assy
01024100105
1
20
Guide Louver
10619405
2
21
Front Connection Board
01349404P
1
22
Fixed Mount
26909426R
1
23
Display Board
30294000009
1
24
Rear Side Plate Sub-Assy
01319442
1
25
Front Connection Board Foam Assy
12509434
1
26
Water Releasing Flume
02289402P
1
27
Stepping Motor
1521240206
2
28
Left Foam Assy
12509437
1
29
Electric Box Assy
01394100344
1
30
Electric Box Cover
01429410P
1
31
Installation Supporting Frame
01809421
1
32
Left Cover Plate
26909416
1
33
Main Board
30226000027
1
34
Terminal Board
42011106
1
35
Terminal Board
4201800002601
1
36
Inductance
43128000014
1
37
Support Of Motor Bearing
01792408
2
38
O-Gasket of Bearing
76512404
2
39
Bracket 1
01809404
1
