Gree GMV-ND22C/A-T Service Manual

GREE GMV5 INDOOR UNIT SERVICE MANUAL
242
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND40SPL/B1-T
CM810N1550
10
Centrifugal Fan
10425200003
4
11
Joint Slack
73018731
2
12
Motor Support
01805200144
1
13
Brushless DC Motor
15704100001
1
14
Rotary Axis Sub-Assy
73018761
2
15
Propeller Housing(Lower)
26905200019
4
16
Cover Of Air-In
01265200085
1
17
Bottom Cover Plate Assy
01264100104
1
18
Water Tray Assy
01285200029
1
19
Electric Box Assy
01394100602
1
20
Terminal Board
4201800002601
1
21
Terminal Board
42011106
1
22
Main Board 2
30227000010
1
23
Main Board
30226000029
1
24
Left Side Plate Assy
01314100136
1
25
Water Pump
4313822001
1
26
Water Level Switch
4501270301
1
27
Drain Hose Sub-Assy
05232050
1
28
Electric Expand Valve Fitting
4304413215
1
29
Electronic Expansion Valve
07334466
1
30
Strainer
07213050
1
31
Strainer
0721200102
1
32
Evaporator Assy
01024100197
1
34
Air Outlet Frame Assy
01374100092
1
35
Top Cover Board Assy
01265200092
1
Above data is subject to change without notice, pls reference the SP in global service website.
