Gree GMV-ND22C/A-T Service Manual

GREE GMV5 INDOOR UNIT SERVICE MANUAL
248
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND22C/A-T
CM400N0140
GMV-ND28C/A-T
CM400N0070
GMV-ND36C/A-T
CM400N0080
GMV-ND45C/A-T
CM400N0150
GMV-ND50C/A-T
CM400N0090
Part code
Quantity
1
Front Panel Assy
20012756
1
2
Filter Sub-Assy
11122139
1
3
Front Case Assy
20012601
1
4
Air Louver(lower)
10512146
1
5
Air Louver(lower)
10512144
2
6
Water Tray
20182140
1
7
Axis(lower step motor)
10542034
1
8
Stepping Motor
1521210101
1
9
Water Tray Assy
20182141
1
10
Strainer
7213029
1
11
Evaporator Assy
1024100143
1
12
Electronic Expansion Valve
7334282
1
13
Electric Expand Valve Fitting
4304000102
1
14
Electric Box Assy
1394100489
1
15
Centrifugal Fan
1394100489
1
16
Brushless DC Motor
15704100012
1
17
Temperature Sensor
3900005910
1
18
Temperature Sensor
390000597
1
19
Temperature Sensor
3900019824
1
20
Let Side Plate
20052011
1
21
Rear Case
22202461
1
22
Top Side Plate
20052013
1
23
Right Side Plate
20052012
1
24
Diversion Circle
10371212
1
25
Louver Motor Sub-assy
21100001
1
26
Swing Lever
10582096
2
27
Guide Louver (upper)
10512145
1
28
Air Louver(upper)
10512143
2
29
Shaft of Guide Louver
10542020
2
30
Rear Grill
1472024
1
31
Crank
73012005
1
32
Stepping Motor
1521210101
1
33
Display Board
30568131
1
34
Pinboard
30278000001
1
35
Terminal Board
42010268
1
36
Electric Board
20112116
1
37
Main Board
30226000080
1
38
Magnetic Ring
49010104
1
39
Shield Cover of Electric Box Sub-assy
01592169
1
40
Remote Controller
30510589
1
Above data is subject to change without notice, pls reference the SP in global service website.
