Gree GMV-ND22C/A-T Service Manual

GREE GMV5 INDOOR UNIT SERVICE MANUAL
264
NO.
Model
GMV-N140U/A-T
Qty.
Product Code
CN750N0030
Part Name
Part Code
9
Cover Plate
01264100061P
1
10
Bidirection Strainer
07220016
2
11
Electronic Expansion Valve
07334412
1
12
Electric Expand Valve Fitting
4304413239
1
13
Display Board
30296000040
1
14
Sensor Sub-assy
39008000130G
1
Exploded View of GMV-N280U/A-T
NO.
Model
GMV-N280U/A-T
Qty.
Product Code
CN750N0020
Part Name
Part Code
1
Electric Box Assy
100002001936
1
2
Electric Box Cover
01424100135P
1
3
Main Board
30226000081
1
4
Terminal Board
42010259
1
5
Terminal Board
42011117
1
6
Wire Clamp
71010003
2
7
Terminal Board
4201800002601
1
8
Electronic Expansion Valve assy
43044100215
1
9
Cover Plate
01264100061P
1
10
Bidirection Strainer
07220016
2
11
Electronic Expansion Valve
07331139
1
12
Electric Expand Valve Fitting
4304413239
1
13
Display Board
30296000040
1
14
Sensor Sub-assy
39008000130G
1
Above data is subject to change without notice, pls refer the SP in global service website.
