MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
10
2 Nomenclature
2.1 Nomenclature of indoor units
GMV
-
N
□
□
□
□
□
/
□
-
□
1
2
3
4
5
6
7
8
9
No.
Description
Options
1
Product code
GMV-Gree Multi VRF Units
2
indoor unit code
indoor unit -N
3
Motor type
D – DC motor
NULL – AC motor
4
Function code
R – pure heat pump/ all heat exchanger with cooling function
L-cooling only unit
X-fresh air
W- double thermal source
Q – heat recovery
Null – electric heating defaulted
5
Cooling capacity/air
volume code
Indoor unit: norminal cooling capacity /100(W)
All heat exchanger: air volume /100
（
m3/h
）
6
Unit type
PL- low static pressure duct type unit;
P-standard static pressure duct type unit
PH- high static pressure duct type unit;
PB-slim type duct type unit
T- 4-way cassete unit;
TX – cassete unit with small panel (4-way air supply)
A-Air handler
；
TD-one-way cassette unit;
TS- two-way cassette unit;
ZD- floor ceiling unit;
ZK- combine unit
C-console unit;
G- wall-mounted unit
；
L- Floor Standing unit
7
With water pump or not
With water pump –S
(S is not displayed for the cassette unit with water pump)
8
Design serial No.
Nominate by A,B,C or expand it by 1, 2, 3…
9
Power
D - 220V～,60Hz; 208-230V～,60Hz; 220-240V～,60HZ; 208/230V～,60Hz;
M - 380V 3N～, 50Hz;400V 3N～,50Hz; 380-415V 3N～,50Hz;
K - 220-240V～,50Hz; 230-240V～,50Hz;
T - 208-230V
～
,60Hz & 220-240V
～
,50Hz
Note:
① If there’s “
（
X+figure
）
”at the end of model, it indicates the fresh air handler. X——fresh air;
Figure (take one decimal fraction) —— air volume (m
3
/h) *10-3. Eg: (X2.0).
② DC inverter fresh air processing indoor, airflow volume ranging from 2000m³/h to 3500m³/h are
available, there’s not “
（
X+figure
）
”at the end of model.
