Gree GMV-ND28C/A-T - Super High Static Pressure Duct Type Indoor Unit

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
213
5.14 Super High Static Pressure Duct Type Indoor Unit
Exploded View of GMV-ND22PHS/B-T、GMV-ND25PHS/B-T、GMV-ND28PHS/B-T、GMV-ND32PHS/B-T、GMV-
ND36PHS/B-T：
17
13
9
7
5
3
1
6
14
20
33
30
29
34
19
10
12
15
22
21
16
28
27
26
25
4
2
31
32
8
11
24
18
23
35
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND22PHS/B-T
CM810N0300
GMV-ND25PHS/B-T
CM810N0310
GMV-ND28PHS/B-T
CM810N0320
GMV-ND32PHS/B-T
CM810N0330
GMV-ND36PHS/B-T
CM810N0340
Part code
Quantity
1
Display Board
'30296000040
1
2
Drain Hose Sub-Assy
'05232050
1
3
Temperature Sensor
'390000454
1
4
Temperature Sensor
'390000592
1
5
Temperature Sensor
'3900005910
1
6
Right Side Plate Assy
'01315200148
1
