Gree GMV-ND28C/A-T - Page 218

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
214
7
Hook
'02112466
4
8
Centrifugal Fan Assy
'15404100074
1
9
Propeller Housing(Upper)
'26905200078
1
10
Return Air Frame Sub-Assy
'017026000004
1
11
Centrifugal Fan
'10455200003
1
12
Supporter(Fan motor)
'0180520027201
1
13
Brushless DC Motor
'1570520000501
1
14
Propeller Housing(Lower)
'26905200079
1
15
Filter Sub-Assy
111001000055
1
16
Foam Sub-assy
'12505200038
1
17
Cover Of Air-In
'01265200182
1
18
Bottom Cover Plate
'01265200181
1
19
Left Side Plate Assy
'01315200147
1
20
Inductance
'43128000014
1
21
Terminal Board
'4201115402
1
22
Terminal Board
4201800002601
1
23
Main Board
'30226000089
1
24
Electric Box Assy
'100002000985
1
25
Choke Plug Of Drain Pipe
'76815214
2
26
Seal Plate Assy
'01495200079
1
27
Water Pump
'43138000058
1
28
Water Level Switch
'45020216
1
29
Electric Expand Valve Fitting
'4304413215
1
30
Strainer
'07415210
1
31
Strainer
'0741410000601
1
32
Electronic Expansion Valve
'07334466
1
33
Evaporator Assy
'011001000296
'01024100171
1
34
Air Outlet Frame Assy
'01374100070
1
35
Top Cover Board Assy
01264100081
1
Above data is subject to change without notice,pls refer the SP in global service website.
