MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
168
No.
Name of part
For the following unit
Unit
Product Code
GMV-ND71PLS/A-T
CM800N3520
GMV-ND80PLS/A-T
CM800N3440
Part code
Quantity
13
Humidity Sensor
0
0
14
Electric Box Assy
'01394100205
1
15
Main Board
'30226000029
1
16
Terminal Board
'4201800002601
1
17
Terminal Board
'42011106
1
18
Electric Box Cover
'01425262
1
19
Left Side Plate Assy
'01315299
1
20
Seal Of Connection Pipe sub-
assy
'01495238
1
21
Left Baffler Sub-Assy
'12505217
1
22
Water Pump
` 4313822001
1
23
Water Level Switch
'45018012
1
24
Electronic Expansion Valve
' 07334466
1
25
Strainer
'0741410000601
1
26
Filter Sub-Assy
'07210028
1
27
Air Outlet Side Board assy
'02225264
1
28
Water Tray Assy
'01285276
1
29
Top Cover Board Assy
'01265350
1
30
Choke Plug of Drain Pipe
'76815214
2
31
Right Baffler Sub-Assy
'12505216
1
32
Right Side Plate Assy
'01315298
1
33
Display Board
'30296000040
1
34
Sensor Sub-assy
'39004169G
1
35
Drain Hose Sub-Assy
'05232050
1
36
Hook
'02112466
4
Above data is subject to change without notice,pls reference the SP in global service website.
