Gree GMV-ND36C/A-T Service Manual

MULTI VRF-Ⅱ INDOOR UNIT SERVICE MANUAL EUROPEAN/LATIN AMETICA (R410A)
197
NO.
Model
GMV-NDX224P/A-T
GMV-NDX280P/A-T
Qty.
Product Code
CM810N0260
CM810N0270
Part Name
Part Code
Part Code
1
Display Board
30296000040
30296000040
1
2
Sensor Sub-Assy
39004165G
39004165G
1
3
Left Side Plate Assy 2
01315367
01315367
1
4
Hook
02112466
02112466
4
5
Left Side Plate Sub-Assy 1
01315376
01315376
1
6
Centrifugal Fan (Left)
1570530601
1570530601
1
7
Brushless DC Motor
15704100009
15704100009
1
8
Centrifugal Fan Assy
15404100075
15404100075
1
9
Blower Mounting Plate Sub-Assy
01324100064
01324100064
1
10
Motor Support
01805200228
01805200228
1
11
Blower(Right)
15705307
15705307
1
12
Front Side Plate Assy
01314627
01314627
1
13
Bottom Cover Plate Assy
01265357
01265357
1
14
Water Tray Assy
01284620
01284620
1
15
Choke Plug of Water Pipe
76712454
76712454
2
16
Electric Box Assy
01394100573
01394100573
1
17
Ritht Side Plate Sub-Assy 1
01314100086
01314100086
1
18
Right Side Plate Assy
01314321
01314321
1
19
Strainer
0741410000601
0741410000601
2
20
Electronic Expansion Valve
07331139
07331139
1
21
Electric Expand Valve Fitting
4304413205
4304413205
1
22
Evaporator Assy
01024100120
01024100120
1
23
Filter Guide Groove
02284107
02284107
2
24
Filter Sub-Assy
11725211
11725211
2
25
Reactor
43130189
43130189
1
26
Terminal Board
4201800002601
4201800002601
1
27
Terminal Board
42010259
42010259
1
28
Main Board
30221000023
30221000023
1
29
Main Board
30226000090
30226000090
1
30
Radiator
49018000068
49018000068
1
31
Top Cover Board Assy
01265359
01265359
1
Above data is subject to change without notice,pls reference the SP in global service website.
