MAINTENACE 01100
GMV5 COMPACT MULTI VRF UNIT
SERVICE MANUAL
4、Remove the
gas-liquid
separator
 Loose the screws fixing
the gas-liquid separator
with screwdriver
5、Replace the
gas-liquid
separator
 Replace the gas-liquid
separator
6、Mount the
gas-liquid
separator
 Tighten the screws fixing
the gas-liquid separator
with screwdriver
Loose the
screws
fixing the
gas-liquid
separator
with
screwdrive
r
Tighten the screws
fixing the gas-liquid
separator with
screwdriver
