Gree GMV5 Compact Series Service Manual

PRODUCT 4 0
GMV5 COMPACT MULTI VRF UNIT
SERVICE MANUAL
 Abundant indoor units
One outdoor unit of GMV5 Compact multi VRF matches different kinds and different capacity of indoor units.
Acording to the use and decoration features of the room, the types of units can be chose includes high static
pressure duct, super slim duct, four-way cassette, one-way cassette, wall-mounted and so on. The units can be
widely used in different size and different uses of the modern household, commercial offices as well as upscale
villas, apartments, penthouse and so on.
3 SPECIFICATIONS
3.1 Specifications
Model
GMV-224WL/A-X
GMV-250WL/A-X
GMV-280WL/A-X
Product Code
CN850W0200
CN850W0210
CN850W0190
Cooling Capacity
KW
22.4
25
28
Heating Capacity
KW
25
28
30
Air Flow Volume
m
3
/h
9000
9000
9000
Sound Pressure
Level
dB(A)
60
61
61
R410A
Filling Amount
kg
7.2
7.6
7.6
EER
W/W
3.34
3.38
3.37
COP
W/W
3.82
3.81
3.68
Phases
-
3
3
3
Rated Voltage
V
380V
380V
380V
Rated Frequency
Hz
50/60
50/60
50/60
Cooling Power
Input
kW
6.70
7.40
8.30
Heating Power
Input
kW
6.54
7.35
8.15
Rated Power Input
kW
8.50
11.30
12.10
Demensions of Unit（mm）
（Width×Depth×Height）
1098×399×1584
1098×399×1584
1098×399×1584
Demensions of Package（mm）
（Width×Depth×Height）
1183×505×1785
1183×505×1785
1183×505×1785
Compressor
QXAS-D32zX050
×2
QXAS-F428zX050B
×2
QXAS-F428zX050B
×2
Moisture Protection
IPX4
IPX4
IPX4
