5 PRODUCT
GMV5 COMPACT MULTI VRF UNIT
SERVICE MANUAL
Note:
① The technical parameters are changed along with the products’improvement; please refer to the nameplate
of the unit for actual data.
② Noise is tested in the semi-anechoic room, so it should be slightly higher in the actual operation due to
environmental change.
③ Rated conditions:
Cooling: Indoor air temperature27℃(81℉)DB/19℃(66.6℉)WB
Outdoor air temperature35℃(95.4℉)DB/24℃(75.6℉)WB
Heating: Indoor air temperature20℃(68℉)DB/15℃(59℉)WB
Outdoor air temperature7℃(44.6℉)DB/6℃(42.8℉)WB
3.2 Operating range
Outdoor Ambient Temperature: 10℃~52℃
Outdoor Ambient Temperature: -20℃~27℃
4 PRODUCT CAPACITY CORRECTION
4.1 Correction factor of indoor and outdoor temperature
a. Correction factor of cooling capacity
