INSTALLATION 0660
GMV5 COMPACT MULTI VRF UNIT
SERVICE MANUAL
5.2.3 High static pressure duct type
① Outline Dimensions:
J
I
H
G
B F
A
E
C
D
Gas Pipe
Liquid Pipe
Drainage Pipe
Electric Box
Air Intake
Max
Max
GMV-ND56PHS/A-T, GMV-ND63PHS/A-T, GMV-ND71PHS/A-T, GMV-ND80PHS/A-T (mm)
A
B
C
D
E
F
G
H
I
J
1101
517
820
1159
1271
558
1002
160
235
268
GMV-ND90PHS/A-T, GMV-ND100PHS/A-T, GMV-ND112PHS/A-T, GMV-ND125PHS/A-T, GMV-ND140PH
S/A-T (mm)
A
B
C
D
E
F
G
H
I
J
1101
748
820
1115
1229
775
979
160
231
290
C
A
D
B
E
F
Air Return
