UNIT GRAVITY CENTER DIAGRAMS
Unit: mm(in.)
GMV-Q72WM/B-F(U), GMV-Q96WM/B-F(U), GMV-Q120WM/B-F(U), GMV-Q144WM/B1-F(U) ;
GMV-Q72WM/B-U(U) ,GMV-Q96WM/B-U(U) ,GMV-Q120WM/B-U(U);
370(14-9/16)
602(23-23/32)
649(25-9/16)
649(25-9/16)
1240(48-13/16)
727(28-5/8)
