Gree GMV6 DC Inverter VRF Units Service Manual
9
Model - GMV-2069WM/G-U GMV-2129WM/G-U GMV-2190WM/G-U GMV-2245WM/G-U
Net weight kg 235+300+355+355 295+300+355+355 295+355+355+355 295+355+355+355
Gross weight kg 245+315+370+370 310+315+370+370 310+370+370+370 310+370+370+370
Model - GMV-2295WM/G-U GMV-2355WM/G-U GMV-2414WM/G-U GMV-2470WM/G-U
HP HP 82 84 86 88
Combination mode
- 20+20+20+22 20+20+22+22 18+22+22+24 20+22+22+24
-
GMV-560WM/G-U+
GMV-560WM/G-U+
GMV-560WM/G-U+
GMV-615WM/G-U
GMV-560WM/G-U+
GMV-560WM/G-U+
GMV-615WM/G-U+
GMV-615WM/G-U
GMV-504WM/G-U+
GMV-615WM/G-U+
GMV-615WM/G-U+
GMV-680WM/G-U
GMV-560WM/G-U+
GMV-615WM/G-U+
GMV-615WM/G-U+
GMV-680WM/G-U
Cooling capacity kW 229.5 235.0 241.4 247.0
Heating capacity kW 258.0 264.0 271.0 277.5
Outdoor static
pressure
Pa 0~110 0~110 0~110 0~110
Noise (sound pressure
level)
dB(A) 71 70 71 72
Power - 440~460V 3~ 60Hz 440~460V 3~ 60Hz 440~460V 3~ 60Hz 440~460V 3~ 60Hz
Cooling power input kW
13.50+13.50+13.50+15.
80
13.50+13.50+15.80+1
5.80
11.90+15.80+15.80+19
.40
13.50+15.80+15.80+19
.40
Heating power input kW
15.35+15.35+15.35+16.
90
15.35+15.35+16.90+1
6.90
13.60+16.90+16.90+19
.50
15.35+16.90+16.90+19
.50
Cooling current input A 19.9+19.9+19.9+23.3 19.9+19.9+23.3+23.3 17.6+23.3+23.3+28.7 19.9+23.3+23.3+28.7
Heating current input A 22.7+22.7+22.7+25.0 22.7+22.7+25.0+25.0 20.1+25.0+25.0+28.8 22.7+25.0+25.0+28.8
Rated power input kW
23.80+23.80+23.80+25.
50
23.80+23.80+25.50+2
5.50
19.40+25.50+25.50+28
.50
23.80+25.50+25.50+28
.50
Rated current A 36.2+36.2+36.2+38 36.2+36.2+38+38 25+38+38+40.9 36.2+38+38+40.9
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 8+8+8+8.3 8+8+8.3+8.3 8+8.3+8.3+8.3 8+8.3+8.3+8.3
Maximum drive IDU
NO.
unit 80 80 80 80
Gas pipe mm Φ44.5 Φ44.5 Φ44.5 Φ44.5
Liquid pipe mm Φ22.2 Φ22.2 Φ22.2 Φ22.2
Outline dimensions (
W
× D × H)
mm
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
Packing dimensions
(W × D × H)
mm
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
Net weight kg 355+355+355+355 355+355+355+355 300+355+355+360 355+355+355+360
Gross weight kg 370+370+370+370 370+370+370+370 315+370+370+375 370+370+370+375
Model - GMV-2525WM/G-U GMV-2590WM/G-U GMV-2655WM/G-U GMV-2720WM/G-U
HP HP 90 92 94 96
Combination mode
- 22+22+22+24 22+22+24+24 22+24+24+24 24+24+24+24
-
GMV-615WM/G-U+
GMV-615WM/G-U+
GMV-615WM/G-U+
GMV-680WM/G-U
GMV-615WM/G-U+
GMV-615WM/G-U+
GMV-680WM/G-U+
GMV-680WM/G-U
GMV-615WM/G-U+
GMV-680WM/G-U+
GMV-680WM/G-U+
GMV-680WM/G-U
GMV-680WM/G-U+
GMV-680WM/G-U+
GMV-680WM/G-U+
GMV-680WM/G-U
Cooling capacity kW 252.5 259.0 265.5 272.0
Heating capacity kW 283.5 291.0 298.5 306.0
Outdoor static
pressure
Pa 0~110 0~110 0~110 0~110
Noise (sound
pressure level)
dB(A) 72 72 72 73
Power - 440~460V 3~ 60Hz 440~460V 3~ 60Hz 440~460V 3~ 60Hz 440~460V 3~ 60Hz
Cooling power input kW
15.80+15.80+15.80+1
9.40
15.80+15.80+19.40+1
9.40
15.80+19.40+19.40+
19.40
19.40+19.40+19.40+19
.40
Heating power input kW
16.90+16.90+16.90+1
9.50
16.90+16.90+19.50+1
9.50
16.90+19.50+19.50+
19.50
19.50+19.50+19.50+19
.50
Cooling current input A 23.3+23.3+23.3+28.7 23.3+23.3+28.7+28.7 23.3+28.7+28.7+28.7 28.7+28.7+28.7+28.7
