Debugging Parameter Reference Value for DC Inverter VRF Unit
No.
Debugging item
Parameter name
Unit
Reference value
Remark
8
System
parameter
Outdoor
unit’s
parameter
System low pressure
℃
（
℉
）
● When the unit operating in the
cooling mode at the ambient
temperature of 25~35
℃（
77~95
℉）
,
the system low pressure value is 0~8
℃
（
32~46.4
℉
）
;
● When the unit operating in the heating
mode at the ambient temperature of -
5~10
℃（
23~50
℉）
, the system low
pressure value is -15~5
℃
（
5~41
℉
）
;
—
9
Opening of electronic
expansion valve of
heating
PLS
● During cooling operation, the
electronic expansion valve of heating is
3000PLS;
● During heating operation, the
adjustable range of the opening of
electric expansion valve opening is
720~3000PLS.
—
10
Operation frequency of
inverter compressor
Hz ● Change among 20Hz~140Hz —
11
IPM module
temperature of inverter
compressor
℃
（
℉
）
● IPM module temperature is lower than
80
℃（
176
℉）
. The highest
temperature doesn’t exceed 95
℃（
203
℉）
.
—
12
Drive bus voltage of
inverter compressor
V
● The normal bus voltage is 1.414 times
of the Power
voltage. For example, if the
three-phase Power
voltage is 208V, then
the rectified bus voltage is: 208V×1.414
= 294V. The normal deviation between
the measured value and the calculated
value within 15V.
—
13
Fan operation
frequency
Hz
● Adjust the operation in the range of
0~75Hz according to the system
pressure adjustment.
—
14
Indoor
unit’s
parameter
Inlet tube temperature
of indoor heat
exchanger
℃
（
℉
）
● According to the ambient temperature,
the inlet temperature is 1
℃（
33.8
℉）
~7
℃（
44.6
℉）
lower than the outlet
temperature for the same indoor unit
under cooling mode.
●The inlet temperature is 10 ~20
℃
（
50~68
℉）
lower than the outlet
temperature for the same indoor unit
under the heating mode.
—
15
Outlet tube temperature
of indoor heat
exchanger
℃
（
℉
）
—
16
Opening of indoor
electronic expansion
valve
PLS
● 2000PLS electronic expansion valve:
the opening is adjusted automatically in
the range of 200~2000PLS;
● 480PLS electronic expansion valve:
the opening is adjusted automatically in
the range of 70~480PLS.
—
17
Drainage
system
— —
● The indoor unit drains smoothly and
thoroughly, and the condensate water
pipe has no slope water storage; the
outdoor unit can drain water from the
drain pipe without dripping directly from
the unit foundation.
—
18 Other — —
●There is no abnormal noise for the
operation of the compressor, indoor fan
and outdoor fan. The unit is running
normally.
—
