Gree GMV6 Series

Gree GMV6 DC Inverter VRF Units Service Manual
4
Model - GMV-504WM/G-U GMV-560WM/G-U GMV-615WM/G-U GMV-680WM/G-U
Rated current A 25.0 36.2 38.0 40.9
Compressor type - Inverter scroll Inverter scroll Inverter scroll Inverter scroll
Compressor function - EVI EVI EVI EVI
Compressor quantity N 1 2 2 2
Refrigeration oil No.
of compressor
- FV68H FV68H FV68H FV68H
Refrige
ration
oil
charge
Gross L 6.1 7.2 7.2 7.2
Compressor
charge
L 1.1 1.1×2 1.1×2 1.1×2
The others L 5 5 5 5
Refrigerant type - R410A R410A R410A R410A
Refrigerant charge kg 8 8 8.3 8.3
Maximum drive IDU
NO.
unit 29 33 36 39
Gas pipe mm Φ28.6 Φ28.6 Φ28.6 Φ28.6
Liquid pipe mm Φ15.9 Φ15.9 Φ15.9 Φ15.9
Outline dimensions
(W × D × H)
mm 1340×775×1690 1340×775×1690 1340×775×1690 1340×775×1690
Packing dimensions
(W × D × H)
mm 1400×830×1855 1400×830×1855 1400×830×1855 1400×830×1855
Net weight kg 300.0 355.0 355.0 360.0
Gross weight kg 315.0 370.0 370.0 375.0
