23
Technical Information
Service Manual
4. Refrigerant System Diagram
HEAT
EXCHANG
E
(EVAPORATOR)
HEAT
EXCHANGE
(CONDENSER
)
COMPRESSOR
CENTRIFUGAL FAN
CENTRIFUGAL FAN
Accumlator
Suction
Discharge
Capillary
Strainer
